2400Mhz To 5850 Mhz RF Triplexers Band Stop Pass Filter

    Buy cheap 2400Mhz To 5850 Mhz RF Triplexers Band Stop Pass Filter from wholesalers

    Buy cheap 2400Mhz To 5850 Mhz RF Triplexers Band Stop Pass Filter from wholesalers
    • Buy cheap 2400Mhz To 5850 Mhz RF Triplexers Band Stop Pass Filter from wholesalers

    2400Mhz To 5850 Mhz RF Triplexers Band Stop Pass Filter

    Ask Lasest Price
    Brand Name : Hansejohn
    Model Number : 2400MHZ LTCC Low Pass Filter, DC -2400 MHz LF3216-2400 /LFCN-2400(+)
    Certification : Pass-band low-loss , high rejection stopband, rectangular coefficient good
    Price : $1-50/pcs
    Payment Terms : Western Union, MoneyGram
    Supply Ability : 1000000
    Delivery Time : 25 day
    • Product Details
    • Company Profile

    2400Mhz To 5850 Mhz RF Triplexers Band Stop Pass Filter

    2400Mhz To 5850 Mhz RF Triplexers Band Stop Pass Filter

    RF Filters

    Low-Pass, High-Pass, Band-Pass, Band-Stop, Diplexers and Triplexers


    ModelPass band insertion loss F1pass band cut-off frequency F2pass band VSWRStop band rejection loss F3Stop band rejection loss F4-F5Stop band rejection loss F6Stop band VSWR
    2400MhzDC-2400.00Mhz <2.0dB2800MhzDC-2400Mhz <2.03600Mhz>20dB3700Mhz-4000Mhz >30dB5000Mhz >20dB3600Mhz-5000Mhz >20
    3000MhzDC-3000.00Mhz <2.0dB3600MhzDC-3000Mhz <2.04550Mhz>20dB4780Mhz-7500Mhz >30dB10000Mhz >20dB4550Mhz-10000Mhz >20
    3800MhzDC-3900.00Mhz <2.0dB4850MhzDC-3900Mhz <2.06000Mhz >20dB6700Mhz-8300Mhz >25dB13000Mhz >20dB6000Mhz-13000Mhz >20
    4000MhzDC-4000.00Mhz <2.0dB4900MhzDC-4000Mhz <2.06150Mhz >20dB6700Mhz-8300Mhz >25dB13000Mhz >20dB6150Mhz-13000Mhz >20
    4400MhzDC-4400.00Mhz <2.0dB5290MhzDC-4400Mhz <2.06700Mhz >20dB7280Mhz-9800Mhz >25dB13000Mhz >20dB6700Mhz-13000Mhz >20
    5000MhzDC-5000.00Mhz <2.0dB5580MhzDC-5000Mhz <2.06850Mhz >20dB7050Mhz-9800Mhz >25dB18000Mhz >20dB6850Mhz-18000Mhz >20
    5500MhzDC-5500.00Mhz <2.0dB6200MhzDC-5500Mhz <2.07200Mhz >20dB7770Mhz-9500Mhz >30dB12100Mhz >20dB7200Mhz-12100Mhz >20
    5850MhzDC-5850Mhz <2.0dB6540MhzDC-5850Mhz <2.07600Mhz >20dB8100Mhz-9900Mhz >30dB12500Mhz >20dB7600Mhz-12500Mhz >20

    Made by low temperature co-firing process, stable structure and high consistency

    Small size, light weight and low power

    The frequency response can be flexibly customized with a center frequency covering 30Mhz to 138Ghz

    SMD chip design, suitable for large-scale patch production process
